Dayton Model 1MBG3 Gear Motor 1 RPM 1/316 Hp 115V (4LL05)

Original price was: $164.70.Current price is: $96.99.

Protect Your Information, Shop with Safe Payments

Buy quality, buy with us.

Efficiency meets excellence in customer care.

Top-Notch Quality

1/316 hp, 1 RPM, 0.5 amps, 115 volts 60hz.
Run Torque 100 inch pounds
Rotation – CW Facing Shaft
Shaft: 5/16″ x 3/4″
Over Hung Pounds = 65
One Year Manufacture Warranty.

Reference: VOO323AH11
Note: 4LL05 Discontinued-this is the replacement.
This motor is mechanically reversible. Simply remove the 2 bolts in the bearing housing, carefully remove the bearing cap assembly, leaving the rotor/shaft in place. Remove the iron stack/coil and turn over, being careful to line up the holes with the bolt holes, reinstall the bearing cap and screws.
