Home / Pool & Spa Motors / Marathon/Leeson Jet Pump Motors
  • 119463.00 Leeson 3 Hp 3600 RPM 208-230/460V 56J Frame (Rigid Base) TEFC 3-Phase Wash-Down Jet Pump Motor -MotorHub Shop 63 front 90952.1643042975
  • H137 Century 1/3 Hp 3-Phase Jet Pump Motor 3600 RPM 208-230/460V ODP 56J Frame (no Base) -MotorHub Shop H137 61305.1670611653
-47%
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base)
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) - Image 2
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) - Image 3
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) - Image 4
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) -MotorHub Shop 1169 left 63794.1605110660
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) -MotorHub Shop 1169 side 20440.1605110666
C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base) -MotorHub Shop 1169 line 40195.1605110670

C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base)

$183.40 Original price was: $183.40.$97.99Current price is: $97.99.

Buy Now
SKU: ZWXLY 1698655277 Categories: Marathon/Leeson Jet Pump Motors, Pool & Spa Motors Tag: Marathon
  • Protect Your Information, Shop with Safe Payments
  • Buy quality, buy with us.
  • Efficiency meets excellence in customer care.
  • Top-Notch Quality
Browse
  • Electric Motors
    • Air Compressor Motors
    • Ametek Lamb Vacuum Motors
    • Bison Gear Motors
    • Dayton Gear Motors
    • Fasco Motors
    • Leeson/Marathon Electric Motors
    • Modine Replacement Motors
    • Motor Controls
    • Unit Bearing Motors
  • HVAC Motors & Draft Inducers
    • Air Condenser Fan Motor
    • Dayton Ventilator Replacement Motors
    • Draft Inducer Venter Motors-Furnace
    • Dual Shaft Motors
    • Furnace Motors
    • Hanging Furnace Motors
    • HVAC-OEM Blower Motors
    • Penn Vent Motors
    • Water Heater Exhaust Blowers
  • Pool & Spa Motors
    • Century Pool & Spa Motors
    • Marathon/Leeson Jet Pump Motors
    • PENTAIR EQ Series Pump Motor
    • US Electric Motors
  • Pulleys and Sheaves
    • 3V Pulley
    • 5V Pulley
    • A/B Pulley
    • AK Sheaves
    • AK-H Pulleys-Bushing Required
    • BK Sheaves
    • BK-H Pulleys-Bushing Required
    • Bushing-Taper Lock
    • C Pulley
    • Die Cast-Fixed Bore
    • Variable Pitch-Fixed Bore
  • Uncategorized
  • Description
  • Reviews (0)
  • 1/2 hp 3600 RPM, 10.8/5.4 amps, 115/230 volts, Capacitor start / Induction run
  • NEMA 56Y Square Flange Frame, 5’8″ dia. by 1-5/8″ long threaded shaft, 60 Hz
  • Service Factor: 1.9, Overload protection: Auto
  • No base, CW rotation viewed opposite shaft end, Ball Bearings; Class B Insulation
  • 1 Year Manufacture Warranty

Spa pump motor having two compartments for easy servicing. Not for pool use due to lack of suction cut-off. ODP = Open Drip Proof, 5KC36MN2508X

Reviews

There are no reviews yet.

Be the first to review “C1169 Marathon 1/2 Hp 2-Comp. Square-Flange Jet Pump Motor 3600 RPM 115/230V ODP 56Y Frame (no Base)” Cancel reply
